Failover Cluster with Replicated Block Volume
This deployment topology is suitable for environments that require site-level redundancy and there is no neutral location for a Witness node.
Solution Prerequisites
Replicated Read/Write Block Volume attachment on both site-A and Site-B recommended via vSphere vSAN or Enterprise Storage Solution with near real time replication
Redundant network connectivity across both sites.
Network latency below 40 ms.
Hardware Requirement
Site Name | Node | CPU Cores | RAM (GB) | Storage (TB) | Operating System |
Site A | Core Platform | 16 | 32 | 300 | Ubuntu-24.04-LTS |
Site A | Reporting | 8 | 16 | 100 | Ubuntu-24.04-LTS |
Site A | Voice Platform | 16 | 32 | 250 | Debian-12 |
Site B | Core Platform | 16 | 32 | 300 | Ubuntu-24.04-LTS |
Site B | Reporting | 8 | 16 | 100 | Ubuntu-24.04-LTS |
Site B | Voice Platform | 16 | 32 | 250 | Debian-12 |
Failover Scenarios
Scenario | Components Failed | Components Active | Business Impact |
|---|---|---|---|
Normal Operation | None | Site-A | Solution is available |
Site Failure | Active Site | Standby site is active. | Brief service interruption during failover, then service resumes on Standby Site |
