Control Plane HA

Control Plane HA is a complete high availability Kubernetes cluster. This deployment requires three Control Plane nodes and two or more Worker nodes.

Suitable when

  • Three sites are available for the cluster deployment. In addition to a primary and a secondary site, a third site for Control Plane is required to complete the quorum.

  • Site level redundancy is needed.

Recommendations

  • Provide a cloud-native storage such as NFS, VSAN, or any CNCF certified cloud-native storage accessible at both sites. Though, CX may be deployed on a Kubernetes cluster where the underlying storage is not a cloud-native storage.

Limitations

  • Out of three control plane nodes, at least two nodes must always be up and connected for the cluster to function.

Deployment Prerequisites

  • At least three control-plane nodes and two or more worker nodes.

  • Full network connectivity between all nodes.

Node Required

vCPU

vRAM

vDisk (GiB)

Comments

RKE2

3 Control Plane nodes

2

4

50

See RKE2 installation requirements for hardware sizing, the underlying operating system, and the networking requirements.

CX-Core

2 Worker nodes

2

4

250

If cloud-native storage is not available, then 2 additional worker nodes are required 1 on site-A and 1 on site-B.

Superset

1 Worker node

2

8

 250

For reporting

Network topology

For load balancing of control planes, consider any of the following three options.

External Load Balancer (ELB)

A Load balancer is used for routing the traffic to the Kubernetes cluster. For a layer-7 load balancer, you may use:

  1. Nginx reverse Proxy

  2. HAproxy or

  3. Any existing load balancer

For setting up an HA cluster using external load balancer, see High Availability using External Load Balancer

KubeVIP

Kube-vip provides Kubernetes clusters with a virtual IP and load balancer for both the control plane (for building a highly-available cluster) and Kubernetes Services of type LoadBalancer without relying on any external hardware or software.High Availability with Kube-VIP

DNS

DNS can be configured to point all the traffic of a domain to any of the needed Control-Plane Nodes High Availability with DNS
